octa low pass gate mixer and matrix

Features

• 8 independent vactrol LPGs.

• Classic logarithmic vactrol curve and latency.

• Two LPG flavours: brighter – blue LEDs – and darker – red LEDs.

• Open design signal path: break the normalization at any point to change its configuration.

• Input and CV are normalled and they flow top to bottom when no jack is inserted.

• Outputs are summed to create sub-mix on the go.

• Unlimited units can be chained together.

• Works with audio and CV sources.

• “Whatever” power connector a.k.a. don’t mind the polarity

Technical Specs

• width 6HP

• depth 28mm

• 150mA +12V

• 90mA -12V

AGOGO is an octal analogue vactrol-based low pass gate and mixer in a cascade configuration.

Configurations with up to 8 inputs combined in 1 output or 1 input splitted into up to 8 outputs are possible thanks to its breakable normalization design.

Inputs are normalled and outputs are mixed: it can be used as a modulation matrix, a signal router or as a multiplier and a mixer for both audio and CV.

More units can be chained to increase the number of I/O.
